11BAppendix C: Command Summary 82BAttribute Summary
95
Appendix C: Command Summary
Attribute Summary
Table 51 lists the attributes for the Object Models in your transducer by Class Code. For more
information on each Object Model, refer to Chapter Four: Operation, page 45.
Table 51: Attribute Summary
Class Code (hex)
Object Model
Instance
ID #
(hex)
Attribute
ID #
(hex) Description Data Type
User
Mode
Access
Cal
Mode
Access
Factory
Default
Setting
01 Vendor UINT R R 36
02 Device Type UINT R R 0
03 Product Code UINT R R 27
04 Revision Struct of:
USINT
USINT
R R current
firmware
revision
05 Status WORD R R 0
06 Serial Number UDINT R R 0
01
Identity
01
07 Product Name SHORT-
STRING
R R CM
01 Node Address USINT RW
1
RW
1
63
02 Data Rate USINT RW
1
RW
1
0 =
125 Kb
03 Bus-Off
Interrupt
BOOL R R 0
03
DeviceNet
01
05 Allocation
Information
Struct of:
USINT
USINT
R R 0, 255
01 03 Trip Point
Assembly
ARRAY R R none
02 03 Poll Request
(No Data)
none R R none
03 03 Poll Response
#1
ARRAY R R none
04
Assembly
04 03 Poll Response
#2
ARRAY R R none
(Continued on next page)
