71BIdentity Object 7BChapter Four: Operation
54
Status
Attribute ID #05 reports the current status of the device in accordance with the ODVA
“DeviceNet Specification,” Volume II [2].
Serial Number
Attribute ID #06 reports the serial num
ber of the device in accordance with the ODVA
“DeviceNet Specification,” Volume
II [2].
Product Name
Attribute ID #07 reports the product nam
e in accordance with the ODVA “DeviceNet
Specification,” Volum
e II [2]. The response returns the ASCII string “CM.”
Identity Object Supported Services
The Identity
Object is supported by the three DeviceNet com
mon services listed in Table 21.
Refer to Supported Service Summary, page 103, for more information.
Table 21: Identity Object Supported Services
Service
ID # (hex) Service Name
Parameter
Data Type(s)
Service
Type Description
05 Reset USINT Request Places the object into its
INITIALIZING state.
0E Get_Attribute_Single USINT Request Reads the object attribute.
10 Set_Attribute_Single USINT,
Attribute Data
Type
Request Modifies the object attribute.
