11BAppendix C: Command Summary 83BSupported Service Summary
103
Supported Service Summary
Table 52 lists the services supported by the Object Models in your transducer by their ID number.
It also lists the Object Models that support each service. The service parameters are defined on
pages 106 to 110. For more information on each Object Model, refer to Chapter Four: Operation,
page 45.
Refer to the ODVA “DeviceNet Specification,” Volum
e I [1]
for complete descriptions of the
common services. Refer to the SEMI Standard Specific Device Models [3, 4, 5] for complete
descriptions of all other services.
Table 52: Supported Service Summary
Service
ID #
(hex)
Service
Name
Parameter
Data
Type(s)
Service
Type Description
Object
Models
05 Reset* USINT Request Places the object
into its Initializing
state.
Identity
Connection
Device
Manager
06 Recover*
(start)
None Request Causes the device to
transition from the
Abort state to the
Operating state.
Device
Manager
07 Abort*
(stop)
None Request Places the device in
its Abort state.
Device
Manager
0E Get_Attribute_Single* USINT Request Reads the object
attribute.
Identity
DeviceNet
Assembly
Connection
Analog Input
Output
Pressure
Device
Config.
Trip Point
Device
Manager
SAC
(Continued on next page)
