Appendix A: Product Specifications
Digital Communication Specifications
Bus Addressing Master/slave information flow
Data Rate Switch/Network Length
Software Override
125 Kb
250 Kb
500 Kb
One, 4-position user-adjustable switch:
PGM (Programmable over the network)
500 m (1,640 ft)
250 m (820 ft)
100 m (328 ft)
DeviceNet V 2.0 Device Group 2 Explicit and Polled Messaging
Digital Functions/Capabilities Read pressure
Set trip points and hysteresis
Select units: Torr, Pa, mBar, inH
2
O, psi
Set digital and analog zeroes
Reset factory defaults
Report run time hours
Monitor transducer status—trip points
Change user tags and device address
Node Address Switches
0/0 to 6/3
6/4 to 9/9
Two, 10-position user-adjustable switches:
Hardware ID numbers (no software override)
Software ID numbers (software selectable)
Network Size Up to 64 nodes
Visual Communication Indicators
(standard bi-color)
LED Module Status (green/red)
LED Network Status (green/red)
