MKS Baratron DMA Series User Manual

77BS-Device Supervisor Object 7BChapter Four: Operation
80
Table 47: Exception Detail Warning Map (continued)
Byte Bit Description Object Model
Common Warning
Size
0 to 7 Byte length always 01 hex Single Byte 2
0 Internal Diagnostic Exception S-Device Supervisor
1 Microprocessor Exception S-Device Supervisor
2-3 EEPROM Exception S-Device Supervisor
4 RAM Exception S-Device Supervisor
5,7 Reserved
Common [Byte 0]
6 Internal Real Time Exception S-Device Supervisor
0 Power Supply Overcurrent S-Device Supervisor
1 Reserved Power Supply S-Device Supervisor
2 Power Supply Output Voltage S-Device Supervisor
3 Power Supply Input Voltage S-Device Supervisor
4 Scheduled Maintenance S-Device Supervisor
5 Notify Manufacturer S-Device Supervisor
6 Reset Exception S-Device Supervisor
Common [Byte 1]
7 Reserved
Device Specific
Warning Size
0 to 7 Byte length always 01 hex Single Byte 3
0 Reading Invalid S-Analog Sensor Object
1 Over-range Exceeded S-Analog Sensor Object
2 Under-range Exceeded S-Analog Sensor Object
Device Specific
Warning Size [Byte 0]
3 to 7 Reserved
0 Not at Temperature S-Analog Sensor Object Device Specific
Warning Size [Byte 1]
1 to 7 Reserved
0 Reserved
1 Reserved
Device Specific
Warning Size [Byte 2]
2 to 7 Reserved
Manufacturing
Specific Warning Size
0 to 7 Byte length always 01 hex Single Byte 1
0 Reserved S-Analog Sensor Object
1 824 Status S-Analog Sensor Object
2 Analog Output Invalid S-Analog Sensor Object
3 Electronics Temperature Alert S-Analog Sensor Object
4 to 5 Reserved
6 Pressure Below 0% Full Scale S-Analog Sensor Object
Manufacturing
Specific Warning
[Byte 0]
7 Pressure Above 100% Full Scale S-Analog Sensor Object
