Mobotix D14D - Default Chapter; Table of Contents

3/126

www.mobotix.com • sales@mobotix.com
Contents
Foreword 6
 8
Superior Storage Solution 10
 2
 4
1 Product Overview 16
  6
  0
  1
1.4 General MOBOTIX Camera Functions 22
  8
1.6 Delivered Parts For D14D/D14D 180° 32
1.6.1 Delivered Parts And Components – D14D 32
1.6.2 Camera Housing And Connectors – D14D 33
1.6.3 Delivered Parts And Components – D14D 180° 34
1.6.4 Camera Housing And Connectors – D14D 180° 35
1.6.5 Dimensions – D14D 36
1.6.6 Dimensions – D14D 180° 37
1.6.7 Delivered Parts Of The Outdoor Wall Mount (Optional Accessory) 38
1.6.8 Delivered Parts Of The Corner And Pole Mount (Optional Accessory) 39
1.7 Available D14D Accessories 40
1.7.1 NPA-PoE Set 40
1.7.2 Replacement Dome 40
1.7.3 Vandalism Set 40
1.7.4 Ethernet Patch Cable With Bayonet Catch 41
1.7.5 Outdoor Wall Mount 41
1.7.6 Corner And Pole Mount 41
1.7.7 ExtIO Function Expansion 41
1.7.8 Mx2wire+ Media Converter 42
1.7.9 Outdoor PatchBox 42
1.7.10 New Functional Boxes (Future Products) 43
2 Mounting 44
  4
2.1.1 Mounting Indoor Cameras To A Ceiling Or Wall (Without Accessories) 44
2.1.2 Outdoor Installation On A Wall, Pole Or Corner (With Accessories) 45
