Delivered Parts For D14D/D14D 180°1.6
Delivered Parts And Components – D14D1.6.1
Item Count Part Name
1.1 1 Camera housing
1.2 2 Lens (installed)
1.3 2 Lens mount
1.4 2 Lock ring (installed)
1.5 2 Sensor cable (integrated, not shown here)
1.6 1 Cable cover (installed)
1.7 2
Dome (1x transparent – integrated, 1x tinted)
1.8 1 Outer shell
1.9 1 Ethernet cable (installed)
1.10 1
Allen wrench 3 mm
1.11 1 TX20 Torx wrench
1.12 1 Custom tool with magnet
1.13 1 MxBus connector (inserted):
1.14 1 MicroSD card, max. of 4 GB (inserted)
Installation accessories
Item Count Part Name
M.1.1 3 Dowels 8 mm
M.1.2 3 Stainless steel washers Ø 5.3 mm
M.1.3 3 Stainless steel wood 4.5x60 mm screws with TX20 head
Custom tool
1x transparent, 1x tinted
