Dansensor A/S COPYRIGHT © P/N 330654-E 01/2018
Lippke 4000/4500 EN User Guide 13
Display (4000-models only)
Monochrome display for setting up of test parameters and for displaying test progresses and
results.
LED indicators (4500-models only)
The 3 LED indicators indicate the following:
• Power (Red) Lit when the instrument is turned on
• RxD (Green) Lit when the instrument is receiving data from the computer.
• TxD (Green) Lit when the instrument is transmitting data to the computer
1
2
3
4657
8
BURST-2 Supervisor
Test result
