Mocon Dansensor Lippke 4500 - Measurement Accessory Kits; Creep2 Fail Test Settings

P/N 330654-E 01/2018 COPYRIGHT © Dansensor A/S
46 User Guide EN Lippke 4000/4500
Measurement accessory kits
The following measurement accessory kits can be used for a Creep2Fail test:
• Stand, basic (with any test head and needle or tube adaptor, with or without filter)
• Fixture f. ASTM restraining (with any test head and needle or tube adaptor, with or without filter)
• Tube adapter
•IV-Bag adapter
• Valve Test Unit (VTU)
• Handheld needle, mono
• Handheld, needle, twin
Creep2Fail test settings
For a Lippke 4500 the test parameters are set in the PC program and for a Lippke 4000 the parameters
are set on the device display.
* = parameter only available in the Lippke 4500 PC Software
Names in parenthesises are the corresponding Lippke 4000 parameter names
Parameters:
Date last modification * Filled out automatically
User * Filled out automatically
Name
(Name)
Test name
Name 1 * Can be used to give additional information about the test
Name 2 * Can be used to give additional information about the test
Package type
(Package Type)
- Normal This is the recommended standard setting. Should
be used whenever possible.
- Porous Use for porous packages like Tyvek.
- Sensitive Do not use for a Creep2Fail test.
Test pressure [mbar]
(Test pressure)
Pressure at which the test is performed
(Typically 95-100% of the burst pressure)
Creep time [sec]
(Creep Time)
The period of time where test pressure is maintained.
With oxygen measurement * Requires a PacCheck 3XX - If checked the O
2
level is measured.
Limit oxygen [%]
(O2 Limit)
Upper limit for acceptable O
2
measurement.
With CO2 measurement * Requires a PacCheck 3XX - If checked the CO
2
level is measured.
Limit CO2 [%] * Upper limit for acceptable CO
2
measurement.
