P/N 330654-E 01/2018 COPYRIGHT © Dansensor A/S
58 User Guide EN Lippke 4000/4500
Setup
Selecting Setup from the Main menu will display the Setup Menu with the available setup parameters
such as Data Transmission, User administration, Language etc.
Each menu item has a submenu with available set-up parameters for the selected item.
Security:
Batch inquiry Yes User has to enter a batch number after choosing a test
record.
No Function disabled.
User Login Yes User has to log in with user name and PIN code
No Function disabled.
Logout after When set time runs out the current user is automatically logged out.
Function is disabled if User Login is set to No or if time is set to 00:00.
Setup Protected Yes Only supervisor users have access to the Setup menu.
Even though user login is disabled, you will be asked to
login at start-up. In this case selecting to Mainmenu from
the User Selection screen will log you in as a user without
supervisor privileges.
No All users have access to the Setup menu.
Settings:
Date Set current date
Time Set current time
Acustic Signal On Enable function.
Off Disable function.
2s - 60s Set the duration of the tone after each test.
Pressure Unit Select unit for pressure values: mbar, mmHG, or psi
NOTE! Observe that the device always uses mbar internally. If
you switch to psi it still operates in mbar but calculates the psi
value for the display.
If f.ex. the 1 mbar step from 34 to 35 mbar is bigger than the
0.01 psi step, then you jump from 0.49 to
0.51 psi.
Security Language
Settings
Data Output
Data Transmission
User Administration
Setup Menu
To Next Page
