How does it work?
1. Adjust the restraining height - see "Adjusting the restraining height (ASTM)" on page 23 for details.
2. Open the restraining plates
 by sliding them away from each other.
3. Prepare the package
 with a septum  and place it on the base plate .
4. Move the test head
 downwards to penetrate the package  making sure that the needle  is
fully seated onto the septum
.
5. Close the restraining plates
. Lock the test head in the current position taking into consideration
that it should be allowed to move upwards as the package inflates.
If, for some reason, you want to restrict the test head movement, you can do this by means of the
knob
.
6. Perform the test.
5
6
7
1
1
2
3
4
