Correct use of hose connectors
Follow procedure below to ensure correct and tight hose connections:
1. Unscrew the union nut
 from the hose connector  and
slide it onto the hose
.
2. Press the hose
 onto the hose connector  as far as it
goes.
3. Finally slide the union nut
 onto the hose connector 
and tighten properly.
2
1
3
