9. Technical Information
Technical specifications
Electrical specifications
Supply voltage 103-264 VAC, 47-63 Hz
Power consumption 50 W
Air supply
Air supply pressure Devices w/ 5 bar “Feed” valve: max. 4.0 bar (58 psi)
Devices w/ 10 bar “Feed” valve: 4.0 - 8.0 bar (58 - 116 psi)
1
The input pressure must be at least 1 bar (14.5 psi) above measurement
pressure
2
Air quality Compliant with DIN ISO 8573 Class 2
3
1
Can be used in range 1 - 4 bar (14.5 - 58 psi) with reduced specifications
2
A separate pressure regulator is recommended
3
See "Filter recommendations" on page 51
Mechanical data
Control unit size 130 x 344 x 262 mm (5.1 x 13.5 x 10.3”) (H x W x D)
Control unit weight 6.5 kg (14.3 lbs)
“Air supply” inlet Hose Ø6/4 mm
“Feed” outlet Hose Ø6/4 mm
“Clamp” outlet Hose Ø6/4 mm
“Sense” inlet Hose Ø4/2.6 mm



