StakMax Microplate Handling System User Guide
5016072 A 39
3. Slide the lock bracket into the baseplate to secure the plate
drawer protection stand. See Figure 2-29.
Figure 2-29 Lock bracket in baseplate
Note: The cartridge drawers cannot open when the StakMax
microplate handler is in place. To open a cartridge drawer, see To open
the cartridge drawer on page 102.
StakMax-UG-5016072A.book Page 39 Friday, October 21, 2011 3:51 PM
