Before cooking on the range top the cover must be in full upright and folded
position. Push the cover toward the outside wall to prevent it from falling onto
the range top during cooking.
• Never close the cover while the burners are in use.
• Do not use the cover as a griddle.
• The oven may be used with the cover down.
• The bi-fold cover must always be closed when the motorhome is
in transit.
WARNING: Do not the heat motorhome interior with the
range or oven. Gas combustion consumes oxygen inside the
motorhome.
• Turn the appropriate burner knob counterclockwise to ON or
LITE. Do not attempt to light more than one burner at a time.
• Turn the SPARK knob clockwise one click. If the burner fails to
light, continue turning the SPARK knob clockwise until the burner
lights.
• To extinguish the top burner flame turn the appropriate burner
knob clockwise to OFF.
WARNING: Top cover must be open when the cooking sur-
face is in operation. Do not cover the oven vent openings
while the oven is in operation.
The burner grate is attached to the cooktop cover by two spring clips located
on the underside of the cooktop cover. The burner grate can be separated from
the cooktop cover for cleaning purposes. Place a towel down onto the countertop
next to the cooktop. Lift the cooktop cover up by the front corners, just high
enough to clear the top of the burners. Pull the cooktop cover toward the front
of the cooktop and lift it away. Place the cooktop cover upside down onto the
towel. Squeeze both of the grate spring clips to remove the grate from cooktop
cover.
WARNING: If you smell gas, extinguish all open flames and
turn off the main gas supply. Liquid propane is highly
volatile, highly explosive and extremely dangerous. Explosion,
fire, property damage, injury or death can result. Propane is a
“heavy” gas and will lay on the floor and “hide” in corners.
Open all windows and doors. Do not touch any electrical
switches. They may cause a spark which can ignite. Contact a
qualified service center to have the problem correctly diag-
nosed and repaired before resuming operation.
Appliances
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT
4•114
Lighting Top Burners
Burner Grate
OM030870.eps
