CHART - FILTERS & BELTS
CHART - SPECIFICATIONS
NOTE: Filter and belt numbers were correct at the time of printing. Verify
the numbers at time of removal. The manufacturer will not be responsible
for incorrect filter or belt usage. Please refer to the engine manufacturer’s
operating instructions for specific maintenance information.
FILTER & BELT MANUFACTURER ISC330
Coolant Filter Fleetquard WF2071
Oil Filter Fleetquard LF 3000
Fuel Filer Primary Raycor S 3201 T
Fuel Filter Secondary Fleetquard FS 1022
Hydraulic Filter Parker INHC 5710
Alternator Belt Dayco 3911581
AC Belt Dayco 17475
Air Filter Donaldson EBA09-2037
MODELS 34PBD 36PBD 38PBD 38PBDD 38PBT 40PBD 40PBDD 40PWD 40PBT
GVWR 31,000 lbs. 31,000 lbs. 31,000 lbs. 31,000 lbs. 31,000 lbs. 31,000 lbs. 31,000 lbs. 31,000 lbs. 31,000 lbs.
GCWR 41,000 lbs. 41,000 lbs. 41,000 lbs. 41,000 lbs. 41,000 lbs. 41,000 lbs. 41,000 lbs. 41,000 lbs. 41,000 lbs.
GAWR (Front) 11,000 lbs. 11,000 lbs. 11,000 lbs. 11,000 lbs. 11,000 lbs. 11,000 lbs. 11,000 lbs. 11,000 lbs. 11,000 lbs.
GAWR (Rear) 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs. 20,000 lbs.
SPECIFICATIONS
These charts reflect product specifications available at the time of printing. Therefore any floor plans introduced thereafter may not be
reflected in the chart. All other information contained throughout the manual will still apply.
MODELS 34PBD 36PBD 38PBD 38PBDD 38PBT 40PBD 40PBDD 40PWD 40PBT
Wheelbase 196" 216" 242" 242" 242" 256" 256" 256" 256"
Overall Length 34'8" 36'4" 38'6" 38'6" 38'6" 39'8" 39'8" 39'8" 39'8"
Overall Height 12'0" 12'0" 12'0" 12'0" 12'0" 12'0" 12'0" 12'0" 12'0"
Interior Height 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6"
Interior Width 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5"
Exterior Width (100.5" floor) 100.5" 100.5" 100.5" 100.5" 100.5" 100.5" 100.5" 100.5" 100.5"
NOTE: This chart reflects product specifications available at the time of printing. Therefore any floor plans introduced thereafter
may not be reflected in the chart. All other information contained throughout the manual will still apply.
