Monaco 2002 Diplomat - Battery Specifications

Electrical Systems - House
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT
8•230
CHASSIS AH (20 HR) CCA
RC (25A)
MINUTES
Chassis
12 Volt Chassis 31P-
MHD (2 each)
240 950 450
6 Volt Domestic
U2200 (4 each)
450* ** 447
*Total battery bank capacity. **Battery connections are made in a Series/Parallel connection. Domestic batteries
are not treated in Cold Cranking Amps (CCA).
VOLTAGE
SPECIFIC
GRAVITY
STATE OF
CHARGE
DEPTH OF
DISCHARGE
12.66 1.265 100% 0%
12.45 1.225 75% 25%
12.25 1.190 50% 50%
12.05 1.145 25% 75%
11.9 1.100 0% 100%
Battery State of Charge vs Voltage/Specific Gravity
CUMMINS ENGINE COLD CRANKING AMPS REQUIREMENTS
ISB 1100 CCA 12 VOLTS
ISC 1250 CCA 12 VOLTS
ISL 1500 CCA 12 VOLTS
ISM 1800 CCA 12 VOLTS
N14 1800 CCA 12 VOLTS
Battery
Specifications
