Before using the washer for the first time wipe the inside and outside with
a damp cloth to remove any travel dust that has accumulated. We recommend
operating a rinse cycle to rinse out the washer.
To begin a wash load:
• Sort and pre-treat clothes (specific directions under sorting).
• Add the measured amount of detergent suggested by the package
directions (maximum two tablespoons).
• Load the clothes loosely into the washer. Close the washer door.
• Turn the cycle selector knob to the desired temperature setting.
• Decide which washing cycle you wish to use. Turn the timer knob
clockwise to the desired wash setting.
• Select High or Medium spin (only for regular washing).
• Press the push button ON.
• After the cycle is complete, wait two minutes for the door lock to
release before attempting to open the door.
CAUTION: Open a window or vent while operating the
dryer. It is dangerous to create negative air pressure inside
the motorhome while operating fuel burning appliances.
WARNING: Do not wash or dry articles that have previous-
ly been cleaned, washed, soaked or spotted with gasoline,
dry cleaning solvents or other flammable or explosive sub-
stances. They give off vapors that could ignite or explode.
Do not add gasoline, dry cleaning solvents or other flammable
or explosive substances to the wash water. Do not use heat to
dry articles containing foam rubber or similar textured, rubber-
like materials. Clean the lint screen if applicable (located on
the back of the washer in the top left corner) after each use
and keep the area around the exhaust opening and adjacent
areas free from the accumulation of lint, dust and dirt.
The removable drain screen, which protects the pump from
lint and foreign matter, needs to be cleaned periodically. The fre-
quency in which it is cleaned depends upon the type of clothes
that are washed. Cotton articles produce more lint than nylon
articles. Under no circumstance should the drain screen be
removed while the machine is full of water. To clean the drain
screen (on an empty machine) open the service door by press-
ing on the left hand side. Place a cloth or shallow tray under the
drain screen housing to catch any remaining water that may drip
out. It may be helpful to first set the machine to spin then
remove the drain screen. This procedure reduces the amount of
water released. Turn the drain screen counterclockwise and pull
the drain screen out. Clean the screen to remove any dirt and
lint. To replace the screen, slide it back into the housing and
turn it clockwise to secure. Close the service door.
Appliances
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT
4•128
Operating
Instructions
OM130608a.eps
Cleaning the Drain Screen
