Monaco 2002 Diplomat - Battery Specifications - Chassis

Electrical Systems - Chassis
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT
9•237
Battery Specifications - Chassis
CCA Rating are at 0º F. These are the minimum requirements.
*Total battery bank capacity. **Battery connections are made in a Series/Parallel connection. Domestic
batteries are not rated in Cold Cranking Amps (CCA).
CHASSIS
Chassis
12 Volt Chassis
31P-MHD (2 each)
6 Volt Domestic
U2200 (4 each)
AH
(20HR)
CCA
RC (25A)
MINUTES
CUMMINS ENGINE COLD CRANKING AMPS REQUIREMENTS
ISB 1100 CCA 12 VOLTS
ISC 1250 CCA 12 VOLTS
ISL 1500 CCA 12 VOLTS
ISM 1800 CCA 12 VOLTS
N14 1800 CCA 12 VOLTS
VOLTAGE
SPECIFIC
GRAVITY
STATE OF
CHARGE
DEPTH OF DISCHARGE
12.66 1.265 100% 0%
12.45 1.225 75% 25%
12.25 1.19 50% 50%
12.05 1.145 25% 75%
11.9 1.1 0% 100%
Battery State of Charge vs Voltage/Specific Gravity
5 AMPS 10 AMPS 15 AMPS 20 AMPS 25 AMPS
U2200 55 22 12.5 9.1 7
Approximate Hours at Ampere Load
240 450
950
450* 447
**
