Monaco 2002 Diplomat - Extend Fixed Dinette; Storage - under Bed

• To extend and add table top leaf unlock and slide table top all the way out
against stop.
• Lift leaf from storage compartment and place it on rails.
• Slide top and leaf against wall.
• Reverse procedure to store table top leaf.
To use the storage compartment located under the bed, locate and unlock the
bed deck latches. Lift up the bed by the front edge of the mattress platform. Gas
struts hold the mattress and platform open.
NOTE: Do not over stress gas struts by rapidly opening or
closing the bed access cover, as this action can damage the
struts or mounts. In extreme cold gas struts may not hold the
mattress platform in the open position.
Equipment
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT
5•166
TO EXTEND FIXED
DINETTE
STORAGE
- UNDER BED
