such conditions, if the slide-out room is already extended,
clear the awning and ensure free movement prior to operat-
ing the slide room.
CAUTION: Dirt and grit trapped under the slide could result
in damage to the floor. Continuous operation of the slide-out
could cause a drain on the house batteries and damage to the
slide motor from overheating.
WARNING: Move the drivers seat forward before activating
the slide-out room. Ensure there is five or more feet of clear
space outside the slide box prior to extending the slide room.
The outside area must be clear of any obstructions which
may hinder the movement of the slide room. Ensure there is suf-
ficient clearance inside the motorhome. Never move the
motorhome with the slide-out extended.
CAUTION: Remove the LOCK’R bar before moving the
slide-out room. Damage can result if it is left in position. The
manufacturer is not responsible for damage resulting from
operating the slide-out room with the LOCK’R left in posi-
tion.
To Retract the Slide-Out Room:
• Check for sufficient clearance inside the motorhome before
retracting the slide-out room.
• Clean the floor, if applicable, to ensure there is no dirt or
grit that could result in floor damage during slide-out
retraction.
• Retract the leveling system prior to operating the slide-out.
• Inspect the exterior of the slide-out to ensure all bay doors
are closed and there are no sags in the awning.
• Prior to retracting the slide-out room, start the motorhome to
allow the air bags to fully inflate.
• Turn the ignition switch OFF. The slide room will not operate
with the engine running.
• The motorhome should be on the air bag suspension prior to
retracting the slide-out room.
• Press and hold the switch in the IN position. The slide-out
room will move slowly in. To stop the slide-out room before
the room reaches the IN position, release the switch. To
continue the room movement, push and hold the switch in.
The motor will change tone when the slide-out room is fully
extended.
Equipment
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT 5•137
Retracting
Main Room
