Mirror Adjust:
To adjust the rear view mirror the small selector in the middle of the
switch must be placed in the desired side. The middle position is to prevent acciden-
tal bumping of the switch and changing the mirror position. The outside mirrors
have been placed so that they can be easily adjusted with the Allen wrench. After
taking delivery of the new motorhome it will be necessary to sit in the driver’s seat
and adjust the mirrors to driver’s needs. Both the driver and the passenger mirrors
should be adjusted.
MIRROR HEATER:
This switch turns on the heaters in outside rear view mirrors. The mirror heaters
should be used when defogging or deicing is needed. To use the mirror heat, press
the switch to the ON position.
NOTE: Mirror heat should not be left on unless continuous fog-
ging conditions occur.
PEDAL IN/OUT:
Use the Pedal In/Out switch to adjust the brake and throttle pedal to be either closer
or farther away. The switch moves the pedals inward or outward approximately three
inches. If it is necessary to move the pedals inward, push the same switch in the
opposite direction. When the pedal comes to the end of the traveling distance there
will be a different sound in the noise of the motor. Stop by releasing the switch. Do
not continue moving the pedals. Damage to the motor and or fuse may result if oper-
ation of the switch continues after reaching the fullest extend or retract position.
Switches (at left)
