Dual Rear Wheels:

Slide the inner dual wheel over the studs, being careful not to damage the

stud threads. Align the handholds for valve access and slide the outer dual

wheel over the studs, again being careful not to damage the stud threads.

Snug the nuts in sequence. Do not tighten fully until all have been seated.

Tighten the nuts to 500 ft. lbs. using the sequence as shown in the illustra-

tion. The hub mount wheels use two piece flange cap nuts for both front and

rear applications. No inner cap nuts are required.

Torque the Nuts Properly:

• Tighten the wheel nuts to the recommended lug nut torque. Do

not over tighten.

• Maintain the nut torque at the recommended level through

planned periodic checks or at 10,000 miles intervals, whichever

comes first.

• If air wrenches are used they must be periodically calibrated for

the proper torque output. Use a torque wrench to check the air

wrench output and adjust the line pressure for the correct torque.

Driving & Safety

------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

DIPLOMAT 2•59
