Electrical Systems - House
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT 8•211
Operation Status Notes
Solid Green Blinking Green
Inverting. Charger ready but
no external AC available.
Normal.
Blinking Green Solid Green
Inverter is in standby.
Battery is being charged.
Normal, charging
current limited if AC
load exceeds Power
Sharing setting.
Converter is in standby.
Charger manually turned off.
If AC power is
removed and
reapplied, the charger
will automatically turn
ON
OFF OFF Inverter OFF. Charging
Reset the Inverter by
pushing INVERT
button. LED should
blink.
Solid Green Blinking Green
Inverting. Charger ready but
no external AC Available.
Battery Voltage Warning:
10V<VDC>15V
Warning. Battery
voltage less than 10
or more than 15 volts.
Solid Green Blinking Green
Inverting. Charger ready but
no external AC available.
Over-temperature Warning.
Warning. Inverter
shutdown.
Battery Voltage shutdown:
10V<VDC>15V
Inverter Shutdown.
Operation will resume
when battery reaches
13.5 volts.
Charger ready but no
external AC power available.
Charger over-temperature
Shutdown
Operation will
automatically resume
after unit has cooled
down.
*
Fast Blinking Red
Inverter Overload Shutdown
Reduce AC load.
Manually restart the
system.
Backfeed Shutdown.
Incorrect AC wiring.
Correct AC in wiring
before use. Manually
restart the system.
TROUBLESHOOTING LED STATUS
Troubleshooting - Inverter/Converter
