Electrical Systems - Chassis
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DIPLOMAT
9•245
CRUISE:
Turns cruise ON or OFF.
CRUISE CANCEL:
Signals the cruise system to disengage without losing the current speed memory set-
ting.
SET/RESUME
• Cruise SET - Actuates the Cruise Set function of the engine controller.
• Cruise RES - Actuates the Cruise Resume function of the engine controller.
WARNING: To take control of the motorhome do not use cruise
control in heavy traffic or on roads that are winding, slippery or
unpaved. Do not shift the transmission into “N” (Neutral) with the
cruise control on as high engine RMP run up will occur until the
cruise control is turned off.
WIPER/WASHER:
Wiper operations are controlled when rotating knob to the right. When the
knob is rotated from OFF to DELAY, the wiper will turn on and time delay
between wipes (ranging from 45 seconds to 2 seconds) will occur. The amount
of delay time changes as knob is rotated. A continuous low or high speed can
be obtained by rotating the knob to the appropriate position. The wipers will
be turned OFF with the switch in the OFF position.
When the end of the knob is pushed in water fluid will be dispensed from the
system and the wipers will turn on momentarily.
