Moons' M2DV-1D82D User Manual

M Series AC Servo
User Manual
130
Rev. 1.0
7/31/2019
400-820-9661
P-35 (JC) Jog mode speed 7
Data Range Default Unit Data type
0.025~100 40 rps DEC
The seventh speed used in velocity mode. This only applies to control modes 13, 14, 17, and 18.
P-36 (JC) Jog mode speed 8
Data Range Default Unit Data type
0.025~100 50 rps DEC
The eighth speed used in velocity mode. This only applies to control modes 13, 14, 17, and 18.
P-37 (ER) Encoder resolution
Data Range Default Unit Data type
200~12800 10000 counts DEC
Sets the encoder resolution in quadrature counts. For example, if the motor connected to the drive has
an 8000count (2000 line) per revolution encoder, set the encoder resolution to 8000.
NOTE: for MOONS’ motor please DONOT change this parameter
P-39 (EG) Electronic gearing
Data Range Default Unit Data type
200~32000 10000 counts DEC
EG defines the pulses per revolution for electronic gearing. For example, with an EG value of 10000 the
servo drive will require 10000 pulses from the master pulse source to move the servo motor 1 revolution.
P-40 (PV) Secondary Electronic gearing
Data Range Default Unit Data type
200~32000 10000 counts DEC
PV defines the pulses per revolution for secondary electronic gearing. Please refer to 7.2.3 control pulse
dividing switch function
P-41 (EN)
Numerator of electronic gearing
ratioNumerator of electronic gearing ratio
Data Range Default Unit Data type
1~1000 1000 DEC
Defines the numerator of electronic gearing ratio.
Please refer to 7.2.5 Electronic gearing ratio
P-42 (EU)
Denominator of electronic
gearing ratio
Data Range Default Unit Data type
1~1000 1000 DEC
Defines the denominator of electronic gearing ratio. Please refer to 7.2.5 Electronic gearing ratio
P-43 (SZ) Input Pulse Setting
Data Range Default Unit Data type
0~65535 1792 DEC
Pulse counter conguration and digital lter parameters in digital position control mode.
Bit0~bit1: pulse type。
Input Noise Filter
Higher 8 Bits
Lower 8 Bits
Pulse Polarity
Pulse Type
0 = STEP/DIR
1 = CW/CCW
2 = A/B quadrature
bit2: count direction
Bit8~bit15：digital filter parameter
Please refer to 7.2.2 input pulse type and input noise lter
