formalin dispensing tank has built-in level sensors that indicate the fluid level and are indicated visually on the
screen. When the tank reaches full capacity, the pump will automatically shut off and the display will visually
show the tank at capacity on the screen.
o An empty system will typically transfer 5 gallons when filling.
• An alarm will alert users when the tank becomes low.
• Mopec recommends refilling the dispensing tank after usage to reduce the crystallization buildup on the float
level sensor.
• To dispense pull the spigot handle. The spigot also has a flow control on the side. Adjust this to your desired
flower rate. With a gravity-fed system, the flow will be the fastest when full and the slowest when empty.
6.2.9 Formalin Collection Option
The Formalin Collection system is also a gravity system that drains from the collection funnel down to a carboy located
on a dolly in the knee space. This will be behind the cabinet doors if your Maestro has that option.
• Pour off formalin waste into the collection funnel, located in the back corner of the sink.
The funnel is necked down to help prevent solids from plugging into the collection line. If desired
Mopec does offer screens (BA077) for the funnel to help collect solids.
BA077
• The system will drain down and into the collection carboy. The carboy cap is equipped with a sensor and will
indicate via an alarm message when the system is full.
• The drain hose is supplied long enough to allow the collection dolly to be pulled out from under the knee space
before disconnecting. This will create a small fluid trap if left at the factory cut length on the collection line.
o If your preference is to eliminate the fluid trap simply trim the line back short enough that the fluid
drains completely into the carboy. You will have to bend down into the knee space to disconnect now.
