63 | P a g e
8.2 How to Repair Product Components
8.2.1 Electrical Panel Service
The Maestro has an electrical service panel located on the sink side of the unit. This panel is where all the power is
distributed to the Maestro. Use a Phillips screwdriver to remove the 10 fasteners.
It is important to leave 10 inches of clearance to access this panel as it houses the PLC, HMI, Electrical DIN
rail, and relays that may need service.
