Morgana Digifold Pro CB - SECTION A; A.5 The Top Cover Assembly

Page10 CREASING/FOLDING
SECTIONA
A.4
A.5
TheControlCover
TheTopCoverAssembly
TheControlCoverfixestothefrontofthemachineandsupportsthecontrolcoverdoorhinge,
withthedoorattached.
Toremovecompletelywiilgiveverylittleaccesstoanything,howeveropeningthedoor
beneaththefeedtablegivesaccesstothemainelectriccontrols.
Toopenthisdoorremovethesixposipanheadscrewsandpivotforwards.
Tocloseisthereverseprocedure.
Note.ensurethisissecurelyclosedwhenfinishedasmainselectricityispresentinside.
TheTopCoverAssemblyishingedontopoftheMachineandcoverstheMechanism,this
hingesupwardstoallowaccesstotheMainRollers,theInputRollers,theCreasing
Assemblies&theTopSensors.
Thiscovercanberemovedfromthemachineasfollows.-
1.OpentheLaySideDooraspreviouslydescribed.
2.Openupwards.
3.Peelbackthesoundabsorbentfoamtoallowaccesstothetwoposipanheadfixing
screwswhichcanbeunscrewedfromthepivotshaft.
4.Fromtherearofthemachineslidetheguardpivotshaftouttakingcarenottodamage
themicroswitch.thecovercannowberemoved.Takecarenottolose/dropthenylonwashers
ateachendofthepivotshaft.
Toreplaceisthereverseprocedure,ensurethemicroswitchiscorrectlysetafterthis
procedure.
