18.CreaseSetup
Parallelism18.1.
Thefirstpartofthisprocessconfirmsifthesheetsteeringhasbeencorrectedbycheckingthe
parallelismofthecreasesproduced.Ifthecreasesarenotparallel,thentheupperinputroller
shouldbeadjustedtocompensate.(SeeFIG.18.1).
FoldLine
PressuresCorrect
PressuresTooHeavy
PressuresTooLight
FeedDirection
Crease1 Crease2
Crease3
FIG.18.1-SHEETSTEER
LaysideInputRoller
Crease1 Crease2
Crease3
FoldLine
Crease1 Crease2
Crease3
FoldLine
LaysideInputRoller
LaysideInputRoller
