Morgana Digifold Pro CB - 18.2. Depth and Edging

Page76
NOTE
DepthandEdging
-thatalthoughthisproceduremayhavealreadybeenperformed,itiscriticalthe
areparallel,evenifthismeansthe'FoldinHalf'testperformedpreviouslyinthe
foldsetup,iscompromisedslightly.
Toadjusttheupperinputrollerfollowthisprocedure.
LoosenthetwoOperatorsidehousingscrews(M5setscrews).
Adjustthelaysidehousingusingtheshaftflatsontheop.side.
TemporarilytightenONEoftheop.sidehousingsetscrews(thetopone).
Re-checkforsheetsteer.(parallelcreasestest).
Repeat1to3untilnosteeringtakesplace.
Tightenbothoftheoperatorsidehousingscrews(M5setscrews).
Ifthelaysidehousingisadjusted,itmaybenecessarytolowerorraisetheentireupper
inputrollersoensuretheloosestsidehassufficient'grip'onasingle80gsmteststrip.If
thisisadjusted,itwillbenecessarytore-checkforsheetsteer.
Oncecreasesareparallelitisthennecessarytocheckthedepthandprofile.Adjustingthe
'BladeBolts'mayberequiredtoremoveanysignsof'edging',andadjustingthe'Blade
Adjusters'willenablethecreasetobemadeheavierorlighteronthedesiredside
creases
18.1.1.
18.1.2.
18.1.3.
18.1.4.
18.1.5.
18.1.6.
18.2.
(SeeFIG.18.2)
FIG.18.2
CREASING/FOLDING
