Morgana Digifold Pro CB - Pre-Power Setup Procedure; 1. Loading Table Alignment

Page40
Pre-PowerSetupProcedure.
The'Pre-PowerProcedure'doesnotrequireconnectiontothemainspowersupplysoleavethe
machinedisconnectedifthecovershavebeenremoved.
TheLoadingTableAssemblyeffectivelyconsistsoftheLoadingTableitself,theFeedSystem&the
ManifoldAirSeparationSystemwhichactsastheFixedSidelayfortheinitialalignmentofthepaper
andthereforemustbesquaretotheinputrollers.
Toallowformanufacturingtolerances,thesquarenessoftheLoadingTableAssemblyiscontrolled
bythetwoM8ButtonHeadScrewswhichallowfore&aftadjustmentoftheoperatorsideofthe
LoadingTable.(SeeFIG.1.5).
Usethefollowingproceduretocheck&adjusttheLoadingTablesquareness:-
RemovetheBallsfromtheSidelay.
OpentheInputRollergapfullybyreleasingtheLockingScrewusinga4mmhexagonkeyto
moveitdowntowardstheLoadingTable.(SeeFIG.1.2below).
PlaceaTestSheetontheLoadingTablewithitsLayEdgeagainsttheFixedSideLay&slide
itthroughtheopenInputRollersuntiltheleadedgejustbecomesvisible.
Donotusedamp,bent,buckledordamagedtestsheets.
1. LoadingTableAlignment:-
1.1.
1.2.
1.3.
WARNING.
FIG.1.2
OperatorSide
LockingScrew
CREASING/FOLDING
