Morgana Digifold Pro CB - Delivery Conveyor Removal

SYSTEM Page11
A.6DeliveryConveyor
ToRemovetheDeliveryConveyortherearcovershouldberemovedforaccess.
Pivotthedeliverydownat45degreesusingthehandleontheendandturnthe‘delivery
lockingscrew’anti-clockwisetolockthedeliverystrutintothisposition.Showninphoto
below.
Usingthebodyofthegasstrutunscrewfromitsclevisuntilreleased.
Unscrewthesupportblockseachsideusinga5mmA/Fallenkeyatthetopfixingand
loosenthebottomscrew.
Pivotbothblocksforward(notetheoperatorsidewillhavearesistancefromtheperfgas
strut)
Theassemblycannowbeliftedclear.
SECTIONA
DeliveryLockingScrew
DigifoldPro
