Morgana Digifold Pro CB - 9. Setting The Fold Knives

Page58
9.SettingTheFoldKnives.
TheFoldKnivesaredrivenbyasteppermotorandarecontrolledbyacamfollowerandcam
profile.Thepositionoftheblackdelrincamiscriticalasitcontrolsthestart&stoppositionsof
theFoldKnives.Greatcareshouldbetakentoensurethatthecenterofthecamisinthecorrect
positionbyadheringtothefollowingprocedureandwithreferencetothediagramsinthe
ServiceManual:-
Loosenalldrivemotorfixingscrews-therearefourM4CapHeads,(
).
LoosenthefrontandrearfixingcapheadscrewsoneachsideoftheDelrinCam
eccentricshaftandpositiontheflatontheshaftverticallyasshownabove.
FromtheLaysideoftheDigiFold,rotatetheKnifeDriveHubsfullycounterclockwise&fit
theSettingJig(PartNo.T-045Rev.C)asshowninthediagrambelowusingthethree
shoulderBoltssupplied.Thislockstheknivesinoneofthetwocorrectstoppositions.
9.1.
9.2.
9.3.
Donotremove
thescrewsbutdocheckthatthereisaplainwasherundereachscrewhead
FixingScrewHeads
insideFrame
FIG.9.1/9.2
Front(A)
Fixings
OpSide
Shaft
Rear(B)
ShaftFixings
insideFrame
DriveMotor
DelrinCam
CREASING/FOLDING
FlatThisSide
