16.DeliveryAssembly
DeliveryBelt
TheDeliveryAssemblyistheretoprovideamovingplatformfortheprocessedsheetstocollect
ontooncefinished.Itconsistof2maincomponents,thedeliverybelt,andthedeliveryroller.
TosetthedeliveryBelttensioncorrectlyitisimperativethatthe2'RollerDriveBelts'arefirst
loosenedtopreventexcessiveloadstothedriverollerbearings.
Lowerthedeliveryuntiltheunitisvertical.
Removethe4fixingscrewsfromthe'UpperEndPanel'and
removethispanel.
Usinga5mmL-SeriesAllenkeyandsuitablelever(aspannerisfine),
loosenthe2buttonheadscrewsthatareusedtosecureeacheccentric
idlertensioner(1eachside).
16.1.
16.1.1.
16.1.2.
16.1.3.
FIG.16.1.2
FIG.16.1.3
ButtonHeadScrew
(1EachSide)
UpperEndPanel
DigifoldPro
SYSTEM
