Morgana Digifold Pro CB - 12. Fold Roller Gap Potentiometers

Page63
12.FoldRollerGapPotentiometers:-
TheFoldRollerGapsarecontrolledbyamechanismwhichusespotentiometerstomeasure
theirpositions.ThisinformationisthenavailabletotheOperatorontheGapSetScreen.These
3Pots,whicharelocatedatthebottomoftheGap-SetMechanismontheOperatorSideofthe
machine,willallrequirecalibrating:-
EntertheGap-SetScreenbyoperatingtheTouchscreen.
LowertheDeliveryUnit,thisenablestherollerstoberotatedeasilyineitherdirection.
Insertan80gsmTestStripintothenipofthefirstFoldRollerbyfeedingtheTestStrip
betweentheLowerRollerShield&theLowerGuide.Itmaybenecessarytomovethe
foldknivestogainaccesstotherollers.
Turnthe1stGapSetAdjustmentKnob(3rdfromtheleft)untilalightpullisevidenton
theteststrip.Loosentherighthandpotentiometercouplingscrew&Rotatethe
potuntilthedisplayforGap1reads0.1.Finallytightenthecouplingscrew.
Insertan80gsmTestStripintothenipofthesecondFoldRollerbyfeedingtheTest
StripbetweenthePaperGuide&UpperRollerShield.Itmaybenecessarytomove
thefoldknivestogainaccesstotherollers.
Turnthe2ndGapSetAdjustmentKnob(2ndfromtheleft)untilalightpullisevidenton
theteststrip.Loosenthecentrepotentiometercouplingscrew&rotatethepotuntilthe
displayforGap2reads0.1.Finallytightenthecouplingscrew.
Insertan80gsmTestStripintothenipofthethirdFoldRollerbydroppingthe
PerforatorAssemblydownfordirectaccesstotheroller.
Turnthe3rdGapSetAdjustmentKnob(1stfromtheleft)untilalightpullisevidenton
theteststrip.Loosenthelefthandpotentiometercouplingscrew&rotatethepotuntil
thedisplayforGap3reads0.1.Finallytightenthecouplingscrew.
12.1.
12.2.
12.3.
12.4.
12.5.
12.6.
12.7.
