Morgana Digifold Pro CB - REMOVAL OF CREASING UNIT

SECTIONC
REMOVALOFCREASINGUNIT:
ThecreasingmechanismAssemblyislocatedinthemiddleofthemachineandcan
Beaccessedbyopeningthetopcover.
1.First,accessshouldbegainedbyremovingthe‘RearCoverAssembly’and‘TopCover
Assembly’.()
2.Removebothtopsecuringblocksbyremovingthetwofixingscrewsfromeachofthem.
3.
4.Removethetopandbottompiniongearswiththecollarsbyusinga10mmspannerto
unscreweachofthepiniongearpostscompletely.
5.Fromunderneaththemachine(disconnectthe
homesensorfromthetiebar,onesocheadallenscrew.
6.Removetheflagfromthehub.Byloosening
thegrubscrewsonthecounterweightandrotating,accesscanbegainedtoremove
thefixingscrews.
7.LoosenthefourM5securingscrewsonthe‘Dynacrease’motortoenableremoval
ofthedrivebelt.
themainframewithcare.
SeeSectionA
Fromthefrontofthemachine,removetheTiltMechanismassemblybyunscrewingthe
twobuttonsocketscrews
Ensurethatthemainsisunplugged)
Cutandremovecableties
fromcablemountingbutleavetheassemblyhanginginside.
(Onlyiftheflagisscrewedontothepulley)
8.Theunitcanbeliftedverticallyoutof
9.Refittingisthereverseprocedure.
Notes.Bladeflag,flatstobeverticalwhen
TDCisselected.Alsothecounterbalance
weightshouldbedownwhenatTDC.
TheBeltmustbetightonfinalassembly.
Page14 CREASING/FOLDING
