CREASING/FOLDINGPage28
SECTIONG
DIAGNOSTICSandCALIBRATIONTOOLS.
SETTHETOTALCOUNTTOZERO.
SETTHEMEASUREMENTSYSTEM(METRIC/IMPERIALSETTINGS).
SETTINGTHEVACUUMDRUMPOSITION.
SETTINGTHEVACUUMDRUMSUCTIONDELAY.
Toentertheengineerstoolsmenu.
TurntheMachineon.
InserttheEngineersPlugintotheSocketlocatedattherearofthemachine.
SelectToolsontheDisplayandcontinuetoselectrequiredtool.
Tosetthetotalcountertozero.
TurntheMachineon.
InserttheEngineersPlugintotheSocketlocatedattherearofthemachine.
SelectToolsontheDisplayandselectthisbutton,
thisvaluedenotestheMachinetotal.
TosetthemeasurementsystemforImperial(Inch)orMetric(mm)thefollowingprocedure
Isnecessary.
Turnthemachineon.
SelectToolsontheDisplayandselect
‘METRICorIMPERIAL’bytogglingthebutton.(whiteisON)
TosetthevacuumdrumstartpositionthefollowingprocedureIsnecessary.
Turnthemachineon.
InserttheEngineersPlugintotheSocketlocatedattherearofthemachine.
SelectToolsontheDisplayandselect‘VacDrumTrim’bytogglingthebutton.
Inputavalueandrun,repeatuntilstartpositioniscorrectunderthepapergate.
Returntothemainscreenandremovetheengineersplug.
TosetthevacuumdrumsuctionstarttimethefollowingprocedureIsnecessary.
Turnthemachineon.
InserttheEngineersPlugintotheSocketlocatedattherearofthemachine.
SelectToolsontheDisplayandselect‘VacSuckTrim’bytogglingthebutton.
Inputavalueandrun,repeatuntilstartdelayiscorrect.
Returntothemainscreenandremovetheengineersplug.
Counterbutton
