Morgana Digifold Pro CB - SECTION C; REMOVAL REPLACEMENT CREASING DRIVE BELT

Page16 CREASING/FOLDING
SECTIONC
REMOVAL/REPLACEMENTCREASINGDRIVEBELT
1.Withthecreasingmechanismoutofthemachineyoucanworkonthebenchto
disassembletheunit.
8.TheBeltcannowbereplaced.
Reassemblyisthereverseprocedurebewarethat
whentighteningthetopswingingblockshoulder
screw,thisshouldbeheldparalleltothepowerlink.
Thiscanbeachievedbypassinga4mmallen
keythroughthesideplateslotandthepowerlinkslot.
2.RemovetheBlade/AnvilAssembly
3.Unscrewthetwocountersunkheadscrewsfromtheinputandoutputguidesand
removethem.
4.Removethefourtiebarsecuringnutsatthe
driveendofthemechanism(Pulleyend).
5.Usinga3.0mmA/Fallenkeyremovethetwo
shoulderbolts.
6.Removethetopswingingblockalongwith
theM6thinwasher.
7.Tapthesideplatefromtheassembly
andremovethebelt.
TheBeltmustbetensionedsothatittakes0.5Kg
topushthebeltuntilitjusttouchesthetiebar.
Thisiscarriedoutbyadjustingthemotordownwards
andispossibletodofromtheoutsideoftheframeby
looseningthefourM5
BeltTightness
Boltsthatlocatethemotor
withinadjustmentslots.
