Morgana Digifold Pro CB - 3. Belt Tension

Page45
FIG.3.1
3.BeltTension:-
Thereare5DrivebeltsontheDigiFoldMechanism&3ontheDeliverysystem.AllDrivebeltsare
XLSeriesTimingBeltsofvariouswidthsandshouldbetensionedinaccordancewiththefollowing
notes.
3.1.AdjustthetensionofthebylooseningthefourM5fixingssecuringthe
MainDriveMotortotheLaysideFramePlate.RaiseorlowertheMotoruntilthecorrect
Tensionisachieved&tightenallfixingswhencomplete.(SeeFIG.3.1).
AdjustthetensionoftheontheDynaCreaseUnitbylooseningthefour
M5fixingssecuringtheBladeDriveMotortotheStepperMountingPlate.Accesstothese
fixingsisviathelargeclearanceholearoundthemotor.RaiseorlowertheMotoruntilthe
correcttensionisachieved&tightenallfixingswhencomplete.(SeeFIG3.1A).
3.3.Ensurethefoldknivesaresetcorrectlyusingthejigbeforesettingthedrivebelttension.
LoosenthefourM5fixingssecuringtheDriveMotortotheFramePlate.
RaiseorlowertheMotoruntilthecorrectTensionisachieved(thisshouldnotbetootight,approx
onequartertwistonthefreelength)&tightenallfixingswhencomplete.(SeeFIG.3.1
3.4.Ensurethefoldknifeflagswitchissetclosetothediameterofthebeltbutnotrubbingon
theflagordrivebelt.
MainDriveBelt
BladeDriveBelt3.2.
MainDrive
Belt
MainDrive
Motor
MainDrive
MotorFixings
BladeDrive
MotorFixings
FoldKnives
DriveMotor
AdjustBlade
DriveBeltTension
AdjustMain
DriveBeltTension
BladeDrive
Motor
FoldKnives
DriveMotor
Fixings
AdjustFoldKnives
DriveBeltTension
FoldKnife
FlagSwitch
