Morgana Digifold Pro CB - 2. Dynacrease Alignment

Page42
2.DynacreaseAlignment:-
TheDynaCreaseUnithasanadjustableTiltMechanismtoenableCreasesquarenessadjustments
tobemadebytheoperatorallowingforvariationsinPrint&PaperStock.Toensurethatthe
operatorhasthefullrangeofadjustmentavailable,thisunitneedstobecentralizedsquaretothe
SideLay(&thereforeparalleltotheInputRollers).
ThesquarenessoftheDynaCreaseUnitiscontrolledbytheTiltMechanismontheOperator
sideofthemachineandbyapairofengineeradjustablePivotBlocksontheLayside.
UsingtheOperatorTiltKnob,rotatetheSpringHubsontheeccentricWormWheelsuntil
theSpringPinsarevertical.(SeeFIG.2.1below).
2.1.
FIG.2.1
SpringPin
SpringPin
SpringHub
Eccentric
WormWheel
TiltKnob
CREASING/FOLDING
