1.4.
1.5.
1.6.
Itshouldbepossibletovisuallychecktheparallelalignmentoftheleadedgeofthe
sheetwiththeUpperInputRoller.(SeeFIG.1.4).
Ifadjustmentisrequired,loosenthetwoM8ButtonHeadScrews(seeFIG.1.5
below)ontheedgeoftheLoadingTableandmovetheoperatorsideinafore&aft
directionuntiltheleadedgeofthetestsheetisparallelwiththeUpperInputRoller.
Tightenbothscrewswhencomplete.
It'simportanttonotethatthelayedgeofthetestsheetmustbekeptincomplete
contactwiththeFixedSideLay(Manifold)duringthisprocess.
FIG.1.5
SideLay(Manifold)
InputRoller
Paper
LeadEdgeofTestSheet
Fixed
Upper
FIG.1.4
LoadingTable
AlignmentScrews
DigifoldPro
SYSTEM
