Morgana Digifold Pro CB - Section D; Loading Table Removal;Replacement

Page18 CREASING/FOLDING
SECTIOND
LOADINGTABLE
RemovaloftheLoadingTable
1.RemovetheSideLaywiththetwolockingKnobs.
2.RemovetheChokeBleedValveknobandtheChokeLockingKnob.
3.RemovetheChokeBleedValvecentershaftbyunscrewingthesoc.setscrew
beneaththeloadingtable.
4.RemovetheEntryGuard.
5.RemovetheFrontFeedBed.
6.UnscrewthefrontLoadingTablecountersunkscrew.
7.FromtherearofthemachineremovethePaperGateAssembly.
8.RemovetheValveassemblyandthemanifoldPortAdaptor.
9.RemovetheM10capheadscrewtoallowaccesstotheBallHolderscrew.
10.RemovethetwofixingscrewsintherearoftheBallHolderAssemblyandremove.
11.LoosentheDisplayfixingscrews(twooff).
12.RemovethefourManifoldfixingscrewsandtheonefixingtheSidelay.
13.Slidethegreenfeedbeltfromthepulleys.
14.RemovethetwoM8buttonheadscrewsfromthefrontoftheLoadingtableandslide
theassemblyfromthemachine.
ReplacingtheLoadingTable.
ReassemblyoftheLoadingTableistheReverseprocedure.
Howevercareshouldbetakenwhensettingthissquaretothemachine.(See‘LoadingTable
