Morgana Digifold Pro CB - Identification; New Machine Preparation

Page3SYSTEM
PanheadandCross-headcountersunkscrewsallhavemetricTaptitethreadsand
Pozi-driverecesses.UseNo.2pointPozidrivorSupadrivdriversforallscrewsM4&
above,andNo.1pointdriversforM3&below.
Warning
Thismachineisheavycareshouldbetaken
whenhandling
iii........Identification
iv........NewMachinePreparation
Forgeneralidentificationofareasofthemachines,thefollowing
termsareused:-
Operatorside(controlpanelfacing)
LaysideorRearofmachine(controlpanelside)
Deliveryend(totheleftoftheoperatorsideie.LeftofFoldRollers)
Feederend(RightofFoldRollers)
Removeallpackagingmaterials
Allmetalparts,includingthefoldingrollershaveaprotectivecoating
Andanyexcessshouldberemoved.
Connectthepowercabletothemainssupply.Themachine
requires230V50Hz10Amps.
Turnthefoldrollersbyhandtoensuretheyrotatefreely.
Switchonthemachineandcheckthatallfunctionsoperate.
Setupthemachinetofoldpaperandcheckthatthemachinefeeds
andfoldscorrectly.
WARNING
WORKSHOULDBECARRIEDOUTBYATRAINEDANDCOMPETENT
ENGINEERANDALLSAFETYPROCEDURESSHOULDBEADHERED
TO.
SWITCHOFFMAINSPOWERBEFORECOMMENCING.
DONOTUSEPHILLIPSDRIVERS-THESEWILLDAMAGETHESCREWS
&MAYSLIP,CAUSINGDAMAGEORINJURY.
DigifoldPro
