Morgana Digifold Pro CB - SECTION E; REMOVAL REPLACEMENT OF INPUT ROLLERS

Page20 CREASING/FOLDING
SECTIONE
REMOVAL/REPLACEMENTOFINPUTROLLERS
Allsidecoversandthetopcovershouldberemovedtoeaseaccesstotheinfeedrollers.
1.Removethemaincreasingmechanismandtiltmechanism.
2.Removetheleadedgesensorhousingbyunscrewingthetwofixingscrewsfromthe
rearofthemachineandleavelooseinsitu.
3.Unscrewandremovetheinputrollergaplockingscrewfromtheslotintheframe.
4.Fromthelaysideofthemachineremovethecirclipfromtheshafthousing.
5.RemovetheDynacreasetiltmechanism.
6.Therollercannowberemovedthroughtheholeintheoperatorsideplate.
6.Removethecirclipfromtheshaftontheoperatorside.
7.Removethepulleyfromtheoppositeendandthenloosenthelaysidehubsecuringset
screwlocatedinthealuminiumsideplateedge.Withdrawtherollerassemblythrough
the
8.Replacetherollerinthereversemanner,butcareshouldbetakentosetthe
Rollergapsandgearmesh.(Seepages50&52).
TOPINPUTROLLER
BOTTOMINPUTROLLER
holeinthelaysidesideplate.
