Morgana Digifold Pro CB - Suction Drum Belt Removal;Replacement

Page19SYSTEM
SECTIOND
SUCTIONDRUMANDBELTREMOVAL\REPLACEMENT
1.Removefeedbedandsideguide.
2.
3.
4.Removesuctiondrumandbelt.
5.LeavethefeeddrumidlerandfeeddrumrollerYoucannowremovebelt.
6.Replaceinreverseorder,becarefulofbearingsandshims.
Removechokeshaftbyunscrewingthesocsetscrewfromunderneath,usinga
2.5mmA/Fallenkey.
Removethebearingcentersupportplatebyunscrewingthetwocapheadscrews.
inposition.
DigifoldPro
