Morgana Digifold Pro CB - SECTION B; B.1 Valve Setting

SECTIONB
B.1ValveSetting.
RemovalofButterflyValveAssembly.
TheButterflyValveassemblyislocatedinsidetherearcoveratthebackofthemachine.
ToremovethevalveAssemblyfirstunplugthecablefromitscontrolboard.
Removethetwopipemountingclipplates(ITEM6onnextpage)sothatthehosescan
bedetachedfromthevalve.
Removethetwoscrewsthatsecurethevalvetotherearoftheframe.
Refitinreverseorder.
Whenrefittingthevalveensurethattheendsofthehosesareclearofnylonfibresandthat
the‘O’ringisinplace.
Donotovertightenaluminumpartsandusegreasetostopbinding.
Note:-
Page12 CREASING/FOLDING
