Morgana Digifold Pro CB - Section a...... Covers; Operator and Layedge Side Doors; Rear Cover

Page9SYSTEM
SECTIONA
A.1
A.2
Covers:
TheOperatorSideDoor.
TheLayEdgeSideDoor
TheOperatorSideDoorcoverwhichissituatedadjacenttotheoperator,coverstheGapSet
mechanismandMainDrivePulleywithitsBelt.
Toremovethiscover,firstremovethetwotopfixingscrewsattachingthetopplate,thismust
beliftedupwardstoclearthegapsetadjusterKnobs.
Removefourscrewsfromtherighthandsideandpivotthedoorforwards.
TheLaySidedoorisattherearofthemachineandissecuredbyfivecountersunkhead
screws.
Removalofthispanelallowsaccesstothesuctionvalve&pipeworkandtheswitchedmode
powersupplies,alsotheFoldKnifedrivemechanismishousedinside.Thetopcoversafety
switchandtheperforatorgasstrutisalsoinsidethiscover.
Toremovethispanelonitsownremoveallcountersunkscrewsattachedtothehingeand
liftaway.
Toreplaceisthereverseprocedure.
AlternativelyremovethefrontandrearcoversalongwiththeRearCoverPanel,seebelow.
Toopen,firstunscrewthesinglepanheadscrewadjacenttothetouchscreenandthenthe
fivepanheadscrewsbelowthefeedbedwhichalsofixestheControlCoverDoorinplace,
hingebackwardstoopen.
Toremovethispanelonitsown,removeallcountersunkscrewsattachedtothehingeandlift
away.
Toreplaceisthereverseprocedure.
AlternativelyremovethefrontandrearcoversalongwiththeRearCoverPanel,seebelow.
TheRearCoverissituatedattheoutputendofthemachinebelowthedeliveryconveyor.This
coverissecuredoneachsidebyfourposipanheadscrews,fixingittothemainframe.Hinges
areattachedeachsideofthecovertoallowthesidetwodoorstopivotfromit.
Toremovetherearcoverincludingtheoperatorsideandlayedgesidedoors,removethe
eightposipanheadscrews(4eachside)andthefivescrewsintherearpanel.
Withtheconveyorfullyupandwithonepersoneachside,theassemblycanbemanouvered
outandunderthereardeliveryconveyor.
Toreplaceisthereverseprocedurecareshouldbetakenandtwopersonsshouldcarrythis
out.
A.3TheRearCoverAssembly
DigifoldPro
