Morgana Digifold Pro CB - SECTION J; REMOVING FITTING OF FOLD KNIFE ASSEMBLIES

Page32 CREASING/FOLDING
SECTIONJ
REMOVING/FITTINGOFFOLDKNIFEASSEMBLIES
Upper
Removethegapsetassembly.
Removethetopcurvedguidebyunscrewingthefourposipanheadscrews(2eachend).
Loosenthesensorandallowtohangfreely.Unscrewthetwocountersunkheadscrews
(oneeachend)usinga4mmallenkeyandremovescrews.Oncethebladeisfreeitcan
beeasilyliftedfromthemachine.
FoldKnife
BottomFoldKnife
ReplacingFoldKnifeAssemblies
Removethelowerrearguideassemblybyremovingthefourposipanheadscrews(2
eachend)whichfixtheblackdelrinblocktothesideplates.
Unscrewthetwocountersunkheadscrews(oneeachend)usinga4mmallenkeyand
removescrews.
Oncethebladeisfreeitcanbeeasilyliftedfromthemachine.
Replacementisthereverseproceduretotheabove.
