Morgana Digifold Pro CB - SECTION K; Main Fold Rollers - Replacement

SYSTEM Page35
SECTIONK
MainFoldRollers-Replacement.
Themainrollersshouldbefittedintothefoldingunitinthereverseorderofremoval.
Procedureforreplacingtherollersisasfollows:-
1.Inserttherollerassemblyintotheframefromtheoperatorsideofthemachine.
2.Replacescrewstolockhubinposition.
3.Theparallelismcannowbeset,.
1.Inserttherollerassemblyintotheframefromthelaysideofthemachine.
2.Replacescrewstolockhubinposition,refitwormwheel(ensurecorrectorientation)
3.Theparallelismcannowbeset,.
2.Replacescrewstolockhubinposition,refitlaysidecollar.
3.Theparallelismcannowbeset, .
ReplaceThe1stRollerAssemblyasfollows:-
ReplaceThe2ndRollerAssemblyasfollows:-
1.InserttherollerassemblyintotheFolderUnitfromtheoperatorsideofthe
machine.
ReplaceThe3rdRollerAssemblyasfollows:-
(Seepage54)
(Seepage54)
(Seepage54)
DigifoldPro
